Phasic Gas (Steam) Cartridge Housing

Description

Phasic Gas (Steam) Cartridge Housing is a high-purity filter using filter cartridge for removing particles in gas. Combined with PTFE High-Efficiency Sterilization Filter, it can be used for filtering sterile gas and fermentation gas; combined with Glass Fiber Filter, it can be used for some high-purity gas filtration; combined with stainless steel filter, it can solve high temperature gas filtration.

The filter element joint is uniformly designed as 226 double seal bayonet type makes cartridge filter owns better sealing performance.



Features

The filter element joint adopts a 226 double seal bayonet type to ensure sealing.

The cartridge number under 3, the filter housing can be adopt quick open, to be convenient and quick when replacing the filter cartridge.



Applications

Sterilization in biotechnology and medicine sector.

Food and beverage sterilization, filtering the steam of heated food.

Moisture filtration in electronics, biotechnology, pharmaceutical and other laboratories

More Description

Operating Conditions

Max Pressure6bar
Max Temperature150 ℃
SterilizationOnline or steam 121 ℃/30min



Connection

Connection of shellFlange/Tri-Clamp
Inlet& Outlet(N1/N2)Flange/Tri-Clamp, Thread
Pressure Gage ( N3 (optional)M14 X1.5 Thread(less than 3 cores)  1/2’’ Thread(less than 5 cores)
Vent/Drain Valve (N4)(optional)1/4’’ Thread
Cartridges Connection226 connection type



Material

Filter shell 304L,316L
Vent Valve/Drain Valve304L, 316L
Sealing ring & GasketEPDM, PTFE, Viton, Silicon



Surface Finish

Finish TypeMechanical polishing / Shot blasting
Polishing precision0.3um inner surface Ra ≤0.6um
0.4um outside surface Ra ≤0.8um




PGH-E-1R-10-F-B
ModelMaterialNo. of cartridgeCartridge filter SizesInlet/Outlet connectionGasket materials
Phasic Gas  Cartridge HousingE=SS 304L
S=SS 316L
1R=1 PCS
3R=3 PCS
5R=5 PCS
9R=9 PCS
12R=12PCS
10=10inch     20=20inch
30=30inch
40=40inch
F=Flange
K=Tri-clamp
T=Crew Thread
B=Buna N
E=EPDM
S=Silicon
V=Viton



Notice: Due to housing has variety in design, please contact with BROTHER sales for more information
