Metalman PSF Cartridge


Pleated stainless steel felt filter cartridge with a large filtration area

What is a metal filter cartridge?

Metal filter cartridges are used in instances where conventional filters are insufficient. This situation may be caused by high temperatures, high pressures, corrosive chemicals, or the necessity to clean and reuse the cartridge. Titanium is occasionally utilized in addition to 316/304 stainless steel as the primary material of the metal filter cartridge.

Brother Filtration introduced a new range named Metalman in the summer of 2022. To meet all kinds of unique filtration requirements, The Metalman comes with a number of unusual metal cartridges. We use titanium in addition to premium stainless steel, and we think these new goods will capture your attention.

What is the Metalman PSF cartridge?

Metalman stainless steel felt cartridge with a large filtration area by folding and forming can achieve absolute filtration accuracy. Stainless steel fiber sintered felt is a porous depth type filter material made of stainless steel fiber sintered at high temperatures.

Brother Filtration manufactures Metalman PSF cartridges in all stainless steel construction, so it has wide chemical compatibility. Also, it can withstand high temperatures and resist corrosion and oxidation. In addition, the PSF filter has a multi-layer structure, which contains a reinforcing layer, protection layer, and main filtration layer, which results in a strong construction that can withstand high pressure.

Stainless steel fibers that have been sintered to provide a high porosity depth filtration material are used to create the distinctive stainless steel sintered felt. A graduated pore size from coarse (upstream) to fine (downstream) is one of the properties of PSF Filter Cartridges, which results in a higher dirt holding capacity and longer service life.

With all characteristics mentioned above, the PSF filter cartridge is a perfect solution for steam filtration or liquids with high viscosities such as sugars and syrups.


Brother Filtration PSF filter is a good filtration solution, the unique design and construction enable its competitive abilities. Besides, it can resist corrosion, high temperature, and oxidation, which fulfills the industries with high demands.

  • All stainless steel construction
  • Wide chemical compatibility
  • Absolute rated
  • Resistance to high temperature, oxidation, and corrosion.
  • Optional protection cover

The outstanding and superior Metalman PSF filter is one of Brother Filtration’s best works. We are confident recommend it to customers who have special needs and higher requests.

  • High dirt-holding capacity
  • Longer service life
  • Good performance for steam and viscous liquids filtration
  • Able to work at 480℃


Inner reinforcing skeleton 316/304 Stainless steel porous plate
Filtration layer
Protective mesh 40 micron 316/304 stainless steel mesh
Main filtration layer 40 micron 316/304 stainless steel mesh
Protective mesh 316/304 Stainless steel porous plate
End Cap 316/304 Stainless steel
Protective Cover( optional) If the working pressure is greater than 0.2 Mpa, it is recommended to add a protective cover to increase the pressure resistance of the cartridge.
Construction SOE, DOE



Number Liquid accuracy(UM) Gas Accuracy(um) Porosity(%) Contamination absorption capacity(mg/cm2) Average permeability(L/dm2 min) Liquid flow (m2/h)
1 3.0 (Imported felt) 0.5 70% 7.9 10 0.8
2 5 1 75% 5 47 1.3
3 7 1.5 76 6.5 63 1.6
4 10 2 75 7.8 105 2
5 25 16 80 19 355 2.5
6 40 25 / / / /
7 60 45 / / / /


Length Filtration Area(indigenous felt) Filtration Area (imported felt)
5inch (127mm) 0.096m2 0.075m2
10inch (254mm) 0.19m2 0.15m2
20inch (508mm) 0.38m2 0.30m2
30inch (762mm) 0.57m2 0.45m2
40inch(1016mm) 0.76m2 0.60m2


Operation condition

Max temperature ~480℃
Max DP 5.0 Bar

Order Information

Model Diameter Filtration Accuracy Cartridge Interface Cartridge Size Seals
PSF=Pleated Sintered felt D65=φ65mm 0300=3.0um E2= Flat pressure 05=5inch S= Silicone Rubber(Silicone)standard
D70=φ70mm 0500=5.0um E4=222 Flush type 10=10inch E= Ternary Ethylene Propylene(EPDM)
/ 0700=7.0um E7=226 Pointed type 20=20inch V=Fluoroelastomer(TEFLON)
/ 1000=10um E8=1” Male NPT 30=30inch P=Fluoroelastomer covered
/ 2500=25um E9=1” Female NPT 40=40inch F=Polytetrafluoroethylene(VITON)
/ 4000=40um / / /
/ 6000=60um / / /
