Max-B Washable High Flow Cartridge Filter

Description

One big tough simple versatile-economical cartridge filter – MAX-B Washable High Flow Cartridge Filter. 100% equivalence to Watt big bubba filter cartridge, which can surely be installed in big bubba Plastic filter housing, with large OD design reducing filter changing times, south Korea imported PP membrane is back-washable to extend life time whilst reducing chemical usage Can be your whole house sediment water treatment meanwhile can be your sea water RO membrane pre-filtration.



Product Features of Max-B Washable High Flow Cartridge Filter

  • Multiple pleated layer construction, filtration configuration in-out .
  • High filtration area up to 8mi.
  • High flow rate up to 36m3/hr (150GPM).
  • High dirt holding capacity
  • Offering greater efficiency, more surface area for a greater throughput and reduced cost
  • 5 straps for reinforcement and internal fixation
  • Replacement for bag filters more filter area
  • Replacement for multiple cartridge filters for greater convenience



Benefits of Max-B Washable High Flow Cartridge Filter

Only ONE Max-B is equivalent to:

  • 18 pcs Melt Blown 40inch φ2.5”
  • 12 pcs Pleated 40inch φ2.5´´
  • 1.6 pcs Bag Filter Size#2



Applications of Max-B Washable High Flow Cartridge Filter

  • Whole house filtration
  • Commercial filtration
  • Industrial filtration
  • Pre-filtration for RO systems
  • Community water systems
  • Sea water application
  • Water for live stock and poultry



Technical Data of Max-B High Flow Filter Cartridge

Materials
Filter Media & Straps Polypropylene
Inner core& End Cap Polypropylene
O-ring EPDM/Buna N/Silicon/Viton
Size
Length 26.25inch
OD 6.3inch
Operation conditions
Max. Temperature ~80 ℃
Recommended DP for change out 2.1-2.4bar



Flow Rate of Max-B High Flow Filter Cartridge



Max Flow Rate
60 inch 36m³/hr
40 inch 24m³/hr
20 inch 12m³/hr



Ordering Information of Max-B High Flow Filter Cartridge



BHFB -P -26 -0500 -E -S
Model Media material Length Micron rating Oring Outer cage


MAX-B high flow filter cartridge





P=polypropylene





26inch=26.25inch



0500=5um

1000=10um

E=EPDM

S=Silicon

V= Viton

B=Buna N







S=Strap

1 inch =25.4 mm
Notice: Due to the filter has variety in design, please contact with BROTHER sales for more information



Housing Options of Max-B High Flow Filter Cartridge

Housing Options of Max-B High Flow Filter Cartridge, Washable High Flow Cartridge Filter
